Pulse Bag Filter Manufacturing Guidelines and Features

The pulse type bag dust collector not only has strong cleaning ability, high dust removal efficiency, low emission concentration, but also has the characteristics of reliable and stable operation, low gas consumption, and small footprint, and is particularly suitable for occasions with large air volume smoke. Pulse bag filter is widely used in cement production line, lime production line, metal magnesium production line, ceramic sand production line, metallurgy, building materials, machinery, chemical industry, electric power, light industry, dust gas purification and recovery of dust materials. What are the manufacturing criteria and characteristics of pulse bag filter?

The pulse type bag dust collector not only has strong cleaningability, high dust removal efficiency, low emission concentration, but also hasthe characteristics of reliable and stable operation, low gas consumption, andsmall footprint, and is particularly suitable for occasions with large airvolume smoke. Pulse bag filter is widely used in cement production line, limeproduction line, metal magnesium production line, ceramic sand production line,metallurgy, building materials, machinery, chemical industry, electric power,light industry, dust gas purification and recovery of dust materials. What arethe manufacturing criteria and characteristics of pulse bag filter?

First, pulse bag filter manufacturing guidelines

1. Standardization criteria for manufacture of pulsed bag dustcollector: The manufacture of dust filter must be arranged according to theplanning drawings and related standard rules, and the manufacturing andinspection of components must be arranged and numbered at the factory.

2. Industrialized criteria for the manufacture of pulsed bagfilter: The precipitator is fully pre-manufactured in the factory, and thecomponents are manufactured in the factory in accordance with the proceduresand methods of the planning drawings.

3. The procedural criteria for the manufacture of pulsed bag dustcollectors: The manufacture of dust collectors shall be in accordance with theprocedures of the equipment installation, and shall be arranged in the order ofmanufacture, storage, shipment and delivery. That is, brackets, ash buckets,upper boxes, maintenance doors, pulse cleaning facilities, ash conveyingfacilities, ash bins, climbing ladder guardrails, duct dust covers, andelectrical appliances.

4. Harmless guideline for pulse bag filter transport: After thefilter is manufactured, it should be scientifically determined according to thecharacteristics of its components and the method of transportation to preventthe components from being distorted, deformed, or otherwise damaged duringtransportation, so that the components can be transported without harm change.

5. Pulse bag filter device integration criteria: Precipitatorprefabricated, device separation device should be combined to provide theoriginal conditions. Strictly ensure the accuracy of the "real-like"scale, make prefabricated components, sensitive and accurate, accurate scale,convenient combination, and processing in place. The main components should bepre-approved before leaving the factory.

Second, the characteristics of pulse bag filter

1. In the external target gas processing power is very strong,stable performance, easy operation.

2. Long life, maintenance workload, reasonable structure, smallfootprint.

3. Cleaning efficiency is high, there is a strong adaptability.

Third, pulse bag filter structure:

The structure of the pulse bag filter can be a beam-column type,or a column-free and beam-free structure supported by a cold-formed steel.

The top of the box of the pulse bag filter is filled with theaccess door, the door-side rotary pulse valve and the air distribution package.If it is a double-span double-row cabinet, the air distribution package is inthe middle of the two spans. If the single row is on the side, the airdistribution package is on the edge. Due to the compact arrangement of thefilter bag inside the pulse bag filter housing, there is not much room forclearance, and the top of the access door to insert or pull out the filter bag,the door of the access door must be aligned with the filter bag, the size ofthe door cover is manufactured also be precise, otherwise it will not cover.

Pulsed bag dust collector beamless column-free box wall steelsheet for enclosure, requiring seal welding, wall panels in the box side with asquare cold-formed steel support, the outside of the box with flat steelstiffened. A gap of 50 mm or more must be left between the outer skin of thestrut skin and the outer surface of the filter bag in the pulse bag filter toprevent wear. The strut wall thickness is not less than 4mm. The rod and rodare welded firmly, and the rod and box wall can be intermittently welded. Theflat steel outside the siding can also be used for intermittent welding, butthe stiffened ends must have welding flesh and must not be opened. If thepressure inside the box is too large, the flat steel can be changed intocold-formed channel steel or square stiffened. The beam-free and column-freebox structure has the advantages of light weight and small steel consumption,and the filter bag room can be manufactured in the factory to install on thesite, which can improve the on-site construction progress.

The pulse bag filter produced by the ZK CORP is in line withmodern savings and green concepts, and our product after-sales service systemis perfect to provide you with the best convenient service in the shortestpossible time.
