In recently year, because of the energy-saving advantage in cement industry by vertical roller mill, the comprehensive benefit become more and more obvious, widely application and popularize in power, metallurgy, chemical industry and nonmetal etc.
Application of Vertical Roller Mill:
Vertical roller mill is mainly used for grinding raw meal, clinker, Ground Granulated Blast Furnace Slag, iron ore, limestone, coal powder, coke powder, coal gangue, fly ash, volcanic ash, gypsum, calcite, pyrophyllite, quartz, clay, sandstone, bauxite and other processing industry related to metal and non-metal mine.
High grinding efficiency and low power consumption.
Low metal consumption in unit product.
Bed grinding with low noise.
Negative pressure and low dust pollution.
Specification & Technical Parameter Table of ZKRM Vertical Raw Mill | ||||||
Model | Pitch diameter of grinding disc (mm) | Capacity (t/h) | Raw material moisture (%) | Raw material fineness (%) | Crude material moisture (%) | Motor Power (kW) |
ZKRM08.2 | 800 | 6-8 | <10% | R0.08<12% | ≤1% | 55/75 |
ZKRM11.2 | 1100 | 10-12 | <10% | R0.08<12% | ≤1% | 110/132 |
ZKRM13.2 | 1300 | 20-25 | <10% | R0.08<12% | ≤1% | 185/200 |
ZKRM15.2 | 1500 | 26-34 | <10% | R0.08<12% | ≤1% | 250/280 |
ZKRM17.2 | 1700 | 40-55 | <10% | R0.08<12% | ≤1% | 355/400 |
ZKRM19.2 | 1900 | 55-70 | <10% | R0.08<12% | ≤1% | 450/500 |
ZKRM20.2 | 2000 | 60-75 | <10% | R0.08<12% | ≤1% | 560/630 |
ZKRM22.3 | 2200 | 85-110 | <10% | R0.08<12% | ≤1% | 710/800 |
ZKRM24.3 | 2400 | 95-130 | <10% | R0.08<12% | ≤1% | 800/900 |
Note: Raw material grindability index ≤13kWh/t |
