NE Plate Chain Bucket Elevator adopt advanced technology from domestic and abroad. This product suitable for vertical conveying powder, granular, bulk and abrasive materials, such as limestone, coal, proppant sand, gravel and so on. Material temperator can not be higher than 200℃ and max lifting can not be more than 40m. block materials, and also for large abrasion material.
Application: Widely used in construction, power, metallurgy, machinery, chemical, mining industry and so on. The temperature of material is below 200℃usually, the height can be reach to 40 meters. NE type bucket elevator adopt flow-through loading, reducing the bucket wearing from material efficiency. Improve the performance of bucket elevator.
Large scope of elevate: not only elevate common powder, particle and block materials, but also can elevate large abrasion materials;
Small power for driving, low energy consumption, save energy effective; compare with roller chain bucket elevator, if elevate same material to same height, energy consume is around 1/3-1/2;
Adoption complete sealing design, there is no dust pollution during operation;
Shell with indent structure , strong rigidity, high precise, nice appearance.
| Model | Elevation Capacity（m³/h） | Maximum Granularity（mm） | Material Loose Density（t/m³) | Maximum Lifting Height (m) | Power（Kw） | Bucket Movement Speed (m/s) |
|---|---|---|---|---|---|---|
| NE15 | 10-15 | 40 | 0.6-2.0 | 35 | 1.5-4.0 | 0.5 |
| NE30 | 18.5-31 | 55 | 0.6-2.0 | 50 | 1.5-11 | 0.5 |
| NE50 | 35-60 | 60 | 0.6-2.0 | 45 | 1.5-18.5 | 0.5 |
| NE100 | 75-110 | 70 | 0.6-2.0 | 45 | 5.5-30 | 0.5 |
| NE150 | 112-165 | 90 | 0.6-2.0 | 45 | 5.5-45 | 0.5 |
| NE200 | 170-220 | 100 | 0.6-1.8 | 40 | 7.5-55 | 0.5 |
| NE300 | 230-340 | 125 | 0.6-1.8 | 40 | 11-75 | 0.5 |
| NE400 | 340-450 | 130 | 0.8-1.8 | 30 | 18.5-90 | 0.5 |
