Screw conveyor has features of compact structure, small cross-sectional area, ligh weight, good sealing, high efficiency, flexible arrangement. It is convenient to assemble, dismantle, move and safety operation. It is suitable to convey all kinds of powdery, granular bulk materials, such as clay powder, coal, cement, sand, small lump coal, gravel, scrap iron etc. But not suitable for sticky agglomerate, perishable materials. Screw conveyor has horizontal and inclined arrangement. It can work with other conveying device to complete the concentrated transportation, distribution, agitation, mixing, dehydration, dosing, unload, stacking operation etc.
Types of Screw Conveyor:Scerw Conveyor in the form of transmission is divided into shaft screw conveyor and shafless screw conveyor, in the shape is divided into U-type screw conveyor and tube screw conveyor.
It achieved clean and environmentally friendly production, especially suitable for conveying dusty, hot (under 200 ℃) and sharp odour material.
The wear treated screw is more wearable and stronger than traditional common screw. It can significantly increase the service life of the screw
It can achieve multi-point feeding and multi-point discharging according to user's process layout.
The redesigned discharging structure makes the discharging smoother.
Main technical parameters of GX series screw conveyor | ||||||||
---|---|---|---|---|---|---|---|---|
Revolving speed (r/min) | Model | |||||||
GX150 | GX200 | GX250 | GX300 | GX400 | GX500 | GX600 | ||
Capacity (m³/ h) | ||||||||
20 | 0.9 | 2.1 | 4.1 | 7.1 | 16.8 | 32.9 | 56.9 | |
30 | 1.3 | 3.2 | 6 2 | 10.7 | 25 3 | 49.4 | 85.3 | |
35 | 1.5 | 3.7 | 7.2 | 12.4 | 29.5 | 57.6 | 99.5 | |
45 | 2 | 4.7 | 9.3 | 16 | 37.9 | 74 | 127.9 | |
60 | 2.6 | 6.3 | 12.3 | 21.3 | 50.5 | 98.7 | 170.6 | |
75 | 3.3 | 7.6 | 15.4 | 26.6 | 63.2 | 123.3 | 213.2 | |
90 | 4 | 9.5 | 18.5 | 32 | 75.8 | 148 | 255.9 |
Main technical parameters of LS series screw conveyor | |||||||
---|---|---|---|---|---|---|---|
Model | Spiral diameter (mm) | Pitch (mm) | Max rev. speed (r/min) | Max. capacity (m³/ h) | |||
Fill coefficient | |||||||
Φ=0.45 | Φ=0.33 | Φ= 0.15 | |||||
LS100 | 100 | 100 | 140 | 3 | 2.2 | 1 | |
LS125 | 125 | 125 | 125 | 5.2 | 3.8 | 1.7 | |
LS160 | 160 | 160 | 112 | 9.7 | 7.1 | 3.2 | |
LS200 | 200 | 200 | 100 | 16.9 | 12.4 | 5.6 | |
LS250 | 250 | 260 | 90 | 29.7 | 21.8 | 9.9 | |
LS315 | 315 | 315 | 80 | 52.9 | 38.8 | 17.6 | |
LS400 | 400 | 355 | 71 | 85.3 | 62.5 | 28.2 | |
LS500 | 500 | 400 | 63 | 133.2 | 97.7 | 44.4 | |
LS630 | 630 | 450 | 50 | 188.9 | 138.5 | 63 | |
LS800 | 800 | 500 | 40 | 270.7 | 198.5 | 70.2 | |
LS1000 | 1000 | 560 | 32 | 379 | 277.9 | 126.3 | |
LS1250 | 1250 | 630 | 25 | 520.5 | 381.7 | 173.5 |
