How does the ceramsite sand production line work?

We are a manufacturer of ceramsite sand equipment. We have rich practical experience in this area. Because the ceramsite sand production line involves many equipments, we ensure that the entire production line works smoothly and we need to be fully prepared in the early stage.

We are a manufacturer of ceramsite sandequipment. We have rich practical experience in this area. Because theceramsite sand production line involves many equipments, we ensure that theentire production line works smoothly and we need to be fully prepared in theearly stage. At the same time, the raw materials for ceramsite sand productionare not high, and can be seen almost everywhere. For example, clay, slate,mudstone, shale, and fly ash can be used as ceramsite sand raw materials.

The working principle of the ceramsite sandproduction line. Regardless of the raw materials used, the production processof homogenization, granulation, roasting and cooling of raw materials isgenerally employed. According to the type and characteristics of the raw materials,the granulation process can have:

1 Mud ball forming process: suitable forfly ash or other powdery raw materials. The process: mixing and homogenizingfly ash, making pellets by granulator, roasting and cooling, and finally makingfinished products.

2 Plastic process: suitable for clay andclay material. The process: plasticizing and homogenizing the clay in ablender, granulating it by a roller granulator, baking, cooling, and finallymaking the finished product.

3 Crushing process: suitable for shale andother raw materials, the process: shale to crushing and grading roasting,cooling finished products.

4. Grinding into a ball process: suitablefor shale, soil shale and coal gangue and other raw materials, the process:shale is first dried, then ball milled and then pre-wet, finally made of discgranulator. The granules are re-baked and cooled → the finishedadmixture.

5 Fuel: Bituminous coal, heavy oil ornatural gas can be used according to the local fuel supply.

Understand the working principle of theceramsite sand production line, which helps to improve the overall performanceof the equipment. The structure of the ceramsite sand production line put intoproduction in the early stage is relatively simple. In the future, we willdevelop into a systematic aspect to meet the needs of different users.
