Deeply cultivating lithium battery materials and equipment: ZK’s flagship product has achieved great results again!

Today, as the new energy wave sweeps the world, lithium battery materials are part of the core industrial chain. The performance and stability of its production equipment directly determines the quality and production capacity of the product. Recently, ZK successfully delivered an HJ300×2.5m double-shaft acid mixer specially customized for lithium battery materials, which once again confirmed its deep technical accumulation in the field of powder and material mixing equipment.

The customer who ordered this equipment this time is an innovative high-tech "little giant" enterprise integrating the research and development, production and sales of new power battery materials. As a global manganese sulfate production service provider for batteries, this customer is not only an enterprise in the industry that masters the key technology of wet-process manganese cathode precursor, but has also successfully opened up the entire industry chain from manganese ore processing to deep processing of manganese-based lithium battery cathode materials. As the demand for new product capacity expansion becomes increasingly urgent, the customer officially placed a purchase order for the HJ300×2.5m double-shaft acid mixer to ZK, which will be used in the core lithium battery material mixed acid section.

It is worth mentioning that this is a repurchase trust from old users. In previous cooperation, the equipment provided by ZK fully met the production needs of customers with its stable operating performance and product performance. During recent after-sales visits and in-depth communication, ZK Business Manager keenly captured the new demands of customers in the construction of new production lines. Based on this, the ZK R&D team made targeted upgrades based on the original equipment and optimized key components such as the acid distributor, observation hole, upper cover plate and ceramic blades. This tailor-made R&D solution not only made the acid distribution more uniform, but also allowed real-time monitoring of the mixing situation, making the operation more convenient. It finally won high recognition from customers and successfully signed a trial production contract.

As the flagship product of ZK, the HJ300×2.5m double-shaft acid mixer is specially designed to cope with harsh working conditions. The equipment adopts a paddle design with a blade rotation diameter of 300mm, a tank length of 2500mm, and a wheelbase of 264mm. Driven by the powerful 11kW reduction motor (model BWD5-23-YVF/11-4P), the spindle speed can be flexibly adjusted between 45-63.5r/min, easily achieving a production capacity of 2-3m³/h. Its working principle is scientific and effective: after the material enters the box from the feed port, the two rotating shafts with stirring blades rotate synchronously, pushing the acid-added materials (such as manganese ore powder and 98% concentrated sulfuric acid) continuously and evenly to the discharge port, integrating acid addition, mixing and transportation.

Acid mixers are widely used in the lithium battery material industry, and their performance is directly related to the purity and consistency of the precursor materials. Over the years, ZK has always kept pace with the development of the industry, continuously optimized the equipment structure and materials according to the actual working conditions of different customers, and successfully reached in-depth cooperation with many well-known domestic and foreign companies. In the future, ZK will continue to uphold the craftsman spirit of excellence and provide high-quality and effective equipment solutions for the new energy materials industry. If you have any related equipment needs, please call our company and we will arrange a dedicated person to receive you and tailor an exclusive solution for you.
