ZSW Series Vibrating Feeder

  • Model:ZSW-380X95,ZSW-600X130
  • Capacity:96-560t/h
ZSW Series Vibrating Feeder is mainly used to feed material into primary crusher evenly and continuously.

Raw Materials:

Granite,limestone,dolomite,iron ore,copper ore...

Application:

Stone Crushing, Ore Dressing

Introduction

ZSW Series Vibrating Feeder is mainly used to feed material into primary crusher evenly and continuously. Meanwhile, it can screen material and strengthen the capacity of the crusher.


This machine takes the dual eccentric shaft vibration exciter through the triangle belt by motor; the exciter's two eccentric axles do the synchronous reverse revolution assured by a pair of meshing gear; the two eccentric axles have certain angle when they are installed, the centrifugal force produced by it makes the sieve body do round straight-line vibration among the vertical direction, the materials move foreward constantly in the process of vibration.

ZSW Series Vibrating Feeder

Product Advantages

  • 01

    Steady vibrating, reliable working and long life.

  • 02

    The flow rate can be changed and controlled at any time.

  • 03

    Low noise and energy consumption.

  • 04

    Simple structure, light weight and small size.

Parameter


ModelMax Feed Size(mm)Capacity(t/h)Motor Power(kw)Size Of Funnel(mm)Weight(kg)
ZSW-380×9550096~160113800×9504800
ZSW-420×95500120~240114200×9505400
ZSW-490×110580120~280154900×11006300
ZSW-590×110600200~350225900×11007300
ZSW-600×130750400~560226000×13009200
