Cement rotary kiln are commonly used for heat processing of minerals and aggregates such as lime, cement, and iron ore. To achieve consistent quality results, it is important to maintain a uniform product temperature at the kiln entry, mid zone, and discharge.
In most rotary kilns, the challenge with temperature process control is that the temperature sensor must view through flames or heavy smoke and dust. Consequently, when selecting a sensor, the design, wavelength, and alignment are all important considerations.
When the material is calcined, the material can be heated evenly and the product quality is stable.
The main transmission system adopts a new type of AC frequency conversion speed regulation technology, and has a large speed regulation range, high efficiency, high speed regulation accuracy, and stable operation.
the bases of the single supporting device and the retaining wheel supporting device are welded, and after the vibration aging treatment is used to eliminate the welding stress, the installation accuracy and reliability of the whole machine can be improved.
Optimized the overall structure of the kiln head and kiln end sections to solve the kiln end return and dust leakage problems that are common in rotary kilns, and the conveying is more smooth and natural.
Model | Diameter(m) | Length(m) | Slope(%) | Capacity(t/d) | Revolving Speed(r/min) | Power(kw) | Weight(t) |
---|---|---|---|---|---|---|---|
Φ2.5×40 | 2.5 | 40 | 3.5 | 180 | 0.44-2.44 | 55 | 149.61 |
Φ2.5×50 | 2.5 | 50 | 3.0 | 200 | 0.62-1.86 | 55 | 187.37 |
Φ2.5×54 | 2.5 | 54 | 3.5 | 280 | 0.48-1.45 | 55 | 196.29 |
Φ2.7×42 | 2.7 | 42 | 3.5 | 320 | 0.10-1.52 | 55 | 198.50 |
Φ2.8×44 | 2.8 | 44 | 3.5 | 450 | 0.437-2.18 | 55 | 201.58 |
Φ3.0×45 | 3.0 | 45 | 3.5 | 500 | 0.5-2.47 | 75 | 210.94 |
Φ3.0×48 | 3.0 | 48 | 3.5 | 700 | 0.6-3.48 | 100 | 237.00 |
Φ3.0×60 | 3.0 | 60 | 3.5 | 800 | 0.3-2 | 100 | 310.00 |
Φ3.2×50 | 3.5 | 50 | 4.0 | 1000 | 0.6-3 | 125 | 278.00 |
Φ3.3×52 | 3.3 | 52 | 3.5 | 1300 | 0.266-2.66 | 125 | 283.00 |
Φ3.5×54 | 3.5 | 54 | 3.5 | 1500 | 0.55-3.4 | 220 | 363.00 |
Φ3.6×70 | 3.6 | 70 | 3.5 | 1800 | 0.25-1.25 | 125 | 419.00 |
Φ4.0×56 | 4.0 | 56 | 4.0 | 2300 | 0.41-4.07 | 315 | 456.00 |
Φ4.0×60 | 4.0 | 60 | 3.5 | 2500 | 0.396-3.96 | 315 | 510.00 |
Φ4.2×60 | 4.2 | 60 | 4.0 | 2750 | 0.41-4.07 | 375 | 633.00 |
Φ4.3×60 | 4.3 | 60 | 3.5 | 3200 | 0.396-3.96 | 375 | 583.00 |
